Application

Crystallizing Slurry | Suspended Solid Slurry
Saturated ChemicalSlurry
General Chemical Slurry

  Face Materials

Carbon / Lecrolloy
Carbon / Ceramic
Carbon / Silicon Carbide
Silicon Carbide / Silicon Carbide
Tungsten Carbide/Tungsten Carbide

  Metal Parts

SS 316, SS 304
Secondary Seal :Elastomers (‘O’ Ring), Viton, Chemraz, Karlez PTFE, GFT (‘V’ Packing)

  Operating Range

Shaft Dia : 22 to 90 mm
Pressure : Up to 12 Bars (max)
Temperature : -20 to +180 C
Velocity : Up to 20 m/sec

  Features

Single acting | Unbalanced | Inside mounted
Independent of direction of rotation
Universal chemical compatability PTFE elastomer
